How to Create a Form Popup Modal in Magento 2

Hello Magento Friends,

How are you all doing? Today I am going to figure out How to Create a Form Popup Modal in Magento 2. Before starting, have a look at our previously published blog, How to get Magento 2 all stores programmatically (Retrieve a list of all stores).

Let’s start with our today’s discussion,

Contents

1 Introduction:
2 Steps to Create a Form Popup Modal in Magento 2:
3 Conclusion:

Introduction:

The modal popup is a child window that requires user interaction before the user can return to the parent window. They help to get work done without showing all information on the main screen.

In Magento 2, you can create modal popups for forms. To create a form popup modal in Magento 2, follow the below steps.

Steps to Create a Form Popup Modal in Magento 2:

Step 1: Firstly, we need to create a “registration.php” file inside our extension folder on this path.

app\code\Vendor\Extension

Now, add the below code as mentioned below

<?php
\Magento\Framework\Component\ComponentRegistrar::register(
    \Magento\Framework\Component\ComponentRegistrar::MODULE,
    'Vendor_Extension',
    __DIR__
);

<?php

\Magento\Framework\Component\ComponentRegistrar::register(

\Magento\Framework\Component\ComponentRegistrar::MODULE,

'Vendor_Extension',

__DIR__

);

Step 2: After that, we need to create a “module.xml” file inside the etc directory of our extension

app\code\Vendor\Extension\etc

And add the below code

<?xml version="1.0"?>
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:Module/etc/module.xsd">
    <module name="Vendor_Extension" setup_version="1.0.0" schema_version="1.0.0"/>
</config>

<?xml version="1.0"?>

</config>

Step 3: After that, we need to create a “routes.xml” file inside etc frontend directory of our extension

app\code\Vendor\Extension\frontend\etc

And add the below-mentioned code

<?xml version="1.0"?>
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:App/etc/routes.xsd">
    <router id="standard">
        <route id="extension" frontName="extension">
            <module name="Vendor_Extension"/>
        </route>
    </router>
</config>

<?xml version="1.0"?>

</route>

</router>

</config>

Step 4: First, we need to create an “extension_index_index.xml” file inside the extension at the following path

app\code\Vendor\Extension\view\frontend\layout

Now, add the code as follows

<?xml version="1.0"?>
<page xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:View/Layout/etc/page_configuration.xsd">
    <body>
        <referenceContainer name="content">
            <block class="Magento\Framework\View\Element\Template" name="custom-form-popup" template="Vendor_Extension::custom.phtml" />
        </referenceContainer>
    </body>
</page>

<?xml version="1.0"?>

<body>

</referenceContainer>

</body>

</page>

Step 5: After that, we need to create a “custom.phtml” file inside the extension on the following path.

app\code\Vendor\Extension\view\frontend\templates

Finally, add the below code

<div id="popup-modal">
    <h3> Add Your Custom Code Here.... </h3>
</div>
<script>
    require(
        [
            'jquery',
            'Magento_Ui/js/modal/modal'
        ],
        function(
            $,
            modal
        ) {
            var options = {
                type: 'popup',
                responsive: true,
                innerScroll: true,
                title: 'Custom Form Popup',
                buttons: [{
                    text: $.mage.__('Close'),
                    class: '',
                    click: function () {
                        this.closeModal();
                    }
                }]
            };

            var popup = modal(options, $('#popup-modal'));

            $('#popup-modal').modal('openModal');
        }
    );
</script>

<h3> Add Your Custom Code Here.... </h3>

</div>

require(

[

'jquery',

'Magento_Ui/js/modal/modal'

function(

modal

) {

var options = {

type: 'popup',

responsive: true,

innerScroll: true,

title: 'Custom Form Popup',

buttons: [{

text: $.mage.__('Close'),

class: '',

click: function () {

this.closeModal();

}

}]

};

var popup = modal(options, $('#popup-modal'));

$('#popup-modal').modal('openModal');

}

);

</script>

Successfully performing the above steps, will show the Custom Form Popup window.

Conclusion:

This way you can Create a Form Popup Modal in Magento 2. If you come across any issues while implementing the above steps, feel free to reach me via the comment section. I will be happy to solve it. Share the article with your friends, colleagues, and social media platforms. Will catch you in the next tutorial, till then stay in the know.

Happy Coding!
