How to Complete a Shopify Draft Order in Shopify Remix Using GraphQL?

In this blog, we’ll learn how to complete a Shopify Draft Order using GraphQL inside a  Shopify Remix app — with one simple and clean code example.

When you create a Draft Order in Shopify, it stays in a “draft” state until it’s completed.

Learn – How to Create a Shopify Draft Order in Shopify Remix Using GraphQL?

Completing the draft order officially turns it into a real Shopify order. In this tutorial, we’ll walk through how to complete a draft order with paymentPending: true, which is especially useful when you want to send an invoice and allow the customer to pay later.

What You’ll Learn

• How to write a GraphQL mutation to complete a Draft Order
• How to handle it in a Remix action() function
• How to build a simple form to trigger the action

Steps to Complete a Shopify Draft Order in Shopify Remix Using GraphQL:

// app/routes/complete-draft-order.jsx
import { json } from "@remix-run/node";
import { Form } from "@remix-run/react";
import { authenticate } from "../shopify.server";

// GraphQL mutation to complete the draft order with payment pending
const COMPLETE_DRAFT_ORDER_MUTATION = `
  mutation draftOrderComplete($id: ID!, $paymentPending: Boolean) {
    draftOrderComplete(id: $id, paymentPending: $paymentPending) {
      draftOrder {
        id
        invoiceUrl
        order {
          id
        }
      }
      userErrors {
        field
        message
      }
    }
  }
`;

// Remix action to handle the POST request
export const action = async ({ request }) => {
  const { admin } = await authenticate.admin(request);
  const formData = await request.formData();
  const draftOrderId = formData.get("draftOrderId");

  try {
    const response = await admin.graphql(COMPLETE_DRAFT_ORDER_MUTATION, {
      variables: {
        id: draftOrderId,
        paymentPending: true,
      },
    });

    const result = response.data.draftOrderComplete;

    if (result.userErrors?.length > 0) {
      return json({ success: false, error: result.userErrors[0].message });
    }

    return json({
      success: true,
      orderId: result.draftOrder.order.id,
      invoiceUrl: result.draftOrder.invoiceUrl,
    });
  } catch (error) {
    return json({ success: false, error: error.message });
  }
};

// UI Form to trigger completion
export default function CompleteDraftOrder() {
  return (
    <div style={{ padding: 20 }}>
      <h2>Complete Draft Order</h2>
      <Form method="post">
        <input
          type="hidden"
          name="draftOrderId"
          value="gid://shopify/DraftOrder/1234567890" // Replace this with your actual Draft Order GID
        />
        <button type="submit">Complete Order (Payment Pending)</button>
      </Form>
    </div>
  );
}

What Happens When You Submit the Form?

• Shopify completes the draft order and marks it as paymentPending.
• You receive a response containing the order ID and invoice URL (if available).
• If there are issues, the mutation returns userErrors, which you can display to the user.

Notes

• Make sure your app has the required access scopes: write_draft_orders and write_orders.
• Replace the dummy draftOrderId with the real one you created earlier.
• You can also use this to send invoices or build custom workflows

You’ve now completed a Shopify Draft Order in Remix using GraphQL.
