How to Use ApexCharts in Laravel 11 with Larapex Charts?

How to Use ApexCharts in Laravel 11 with Larapex Charts

In this guide, we’ll walk you through integrating ApexCharts in your Laravel 11 application using the Larapex Charts package. This package provides a simple way to work with ApexCharts in Laravel.

Laravel Development Services

ApexCharts is a JavaScript library used for creating beautiful and interactive charts on websites. It makes it easy to visualize data through various chart types like bar, line, pie, and more.

Steps to Use ApexCharts in Laravel 11:

Step 1:  Install Laravel 11

composer create-project laravel/laravel Apexchart

Step 2: Install ApexChart

composer require arielmejiadev/larapex-charts

Then publish Apex chart configuration

php artisan vendor:publish –tag=larapex-charts-config

Step 3: Make Controller for MonthlyUsersChart

php artisan make:controller MonthlyUsersChart

Add the below code

<?php

namespace App\Charts;
use ArielMejiaDev\LarapexCharts\LarapexChart;
use App\Models\User;
use DB;

class MonthlyUsersChart
{
    protected $chart;
    /**
     * Write code on Method
     *
     * @return response()
     */
    public function __construct(LarapexChart $chart)
    {
        $this->chart = $chart;
    }
    /**
     * Write code on Method
     *
     * @return response()
     */
    public function build()
    {
        $users = User::select(DB::raw("COUNT(*) as count"), DB::raw("MONTHNAME(created_at) as month_name"))
                    ->whereYear('created_at', date('Y'))
                    ->groupBy(DB::raw("Month(created_at)"))
                    ->pluck('count', 'month_name');
        return $this->chart->pieChart()
            ->setTitle('New Users - '.date('Y'))
            ->addData($users->values()->toArray())
            ->setLabels($users->keys()->toArray());
    }
}

Step 4: Make Controller for ApexChart

php artisan make:controller ApexChartController

Add the below code

<?php

namespace App\Http\Controllers;
use Illuminate\Http\Request;
use App\Charts\MonthlyUsersChart;

class ApexchartsController extends Controller
{
    public function index(MonthlyUsersChart $chart)
    {
        return view('apexcharts', ['chart' => $chart->build()]);
    }
}

Step 5: Create Route

Routes are defined in the Web.php file

Route::get('magecomp-chart', [ApexchartsController::class, 'index']);

Step 6: Create Blade File for Chart

<!DOCTYPE html>

<html>
<head>
    <title>Laravel 11 Apexcharts Chart Example - ItSolutionStuff.com</title>
    <link href="https://cdn.jsdelivr.net/npm/bootstrap@5.0.2/dist/css/bootstrap.min.css" rel="stylesheet" crossorigin="anonymous">
</head>
<body>
    <div class="container">
        <div class="card mt-5">
            <h3 class="card-header p-3">Laravel 11 Apexcharts Chart Example - ItSolutionStuff.com</h3>
            <div class="card-body">
                {!! $chart->container() !!}
            </div>
        </div>
    </div>
</body>
<script src="{{ $chart->cdn() }}"></script>
{{ $chart->script() }}
</html>

Step 7: Cerate Dummy Record using Tinker

php artisan tinker
User::factory()->count(30)->create()

Step 8: Run Project

php artisan serve

and hit this url

https://localhost:8000/chart

Conclusion:

Using ApexCharts with Larapex Charts in Laravel 11 makes it simple to create visually appealing charts. This guide covered installation, chart creation, and integration within a Blade view. You can further customize charts to suit your application’s needs.

Hire laravel Developer

Happy Coding!
